Get in touch with highly dynamic temperature control system experts
적합한 냉각기를 찾을 수 없나요? 또는 냉각기를 선택하는 방법을 모르시나요? 지금 바로 문의하여 냉각기 세부 정보 및 가격을 알아보세요.
LNEYA®에 문의하세요
요청을 제출하시면 24시간 이내에 연락드리겠습니다.
highly dynamic temperature control system
SUNDI Z SERIES
Temp range -80℃~250℃ Temp accuracy ±0.1℃
highly dynamic temperature control system characteristics
SUNDIZ variable frequency series products use variable frequency control for refrigeration and circulation systems compared to SUNDI products. Compared with old products, they save more than 20% energy, reduce noise by more than 5 decibels, and have a small starting current. By increasing the frequency, increasing the refrigeration power, and improving the cooling rate, the circulating pump variable frequency control.
High-precision temperature control in laboratories, pilot plants and industry with its compact size and unique thermodynamic properties
For process engineering applications such as temperature control of reactors, autoclaves, mini-plants/pilot plants, reaction zones and calorimeters.
laboratory thermostats Video
The fully closed cycle design eliminates medium volatilization and moisture absorption, and supports low-temperature automatic refilling to ensure long-term stable operation of the system.
In addition, the SUNDI series process chiller adopts ultra-high temperature cooling technology, which can quickly cool directly from 300℃, and is equipped with magnetic variable frequency pumps and variable frequency compressors to achieve energy saving and silence.
SUNDI -10℃~+150℃
냉각 난방 장치
냉각 용량 2.1kW~15kW
난방 전력 3.5kW~15kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
SUNDI -25℃~+200℃
냉장 가열 서큘레이터
냉각 용량 1.8kW~200kW
난방 전력 3.5kW~200kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
SUNDI -45℃~+250℃
난방 냉각기
냉각 용량 0.25kW~200kW
난방 전력 2.5kW~200kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
SUNDI -60℃～+250℃
온수기 및 냉각기
냉각 용량 0.25kW~60kW
난방 전력 2.5kW~60kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
SUNDI -80℃~+250℃
냉각기 공조
냉각 용량 0.3kW~80kW
난방 전력 3kW~80kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
SUNDI -90℃~+250℃
냉각기 히터 콤보
냉각 용량 0.5kW~80kW
난방 전력 5.5kW~80kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
SUNDI -100℃~+100℃
재순환 히터 냉각기
냉각 용량 0.7kW~80kW
난방 전력 5.5kW~80kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
SUNDI-320
휴대용 냉각기
냉각 용량 0.4kW~1.5kW
난방 전력 2kW
중간 온도 정확도 ±0.5℃
재료 온도 정확도 ±1℃
Highly Dynamic Temperature Control System Applications
As a chiller manufacturer, we support highly dynamic temperature control system to meet your applications with competitive quality, price and service.
SUNDIZ water chiller heaters have been widely used in pharmaceutical chemicals, bioproduction, aerospace industry, semiconductor industry, etc. due to their excellent cooling and heating capabilities and precise temperature control accuracy.
For glass reactors temperature control
Connect the reactor jacket through the external circulation pipeline to absorb or release heat in real time. Automatically adjust the hot and cold output according to the pressure change in the reactor to ensure temperature stability during strong exothermic/endothermic reactions.
For Microchannel reactor
high-sensitivity sensors capture microliter-level fluid temperature changes in real time, adjust the opening of the electronic expansion valve, and ensure the stability of temperature control.
반도체 제조용
Applicable to fast and precise cooling and heating in semiconductor ion implantation, etching, chip packaging, testing, lithography, wet cleaning and other process processes to improve yield and extend equipment life.
For semiconductor material aging test
Accelerate material aging and provide extreme high temperature and low temperature environment for material durability and reliability testing.
For distillation system temperature control
Compact structure, precise adjustment of distillation temperature, suitable for small-scale laboratory operation, energy-saving and efficient, easy to operate, and highly flexible.
For vcuum chamber temperature control
Adapt to the vacuum environment to stabilize the output temperature at the set temperature and avoid thermal fluctuation interference.
LNEYA provides two options: water-cooling & air-cooling highly temperature control system
1.Cooling efficiency
The power supported by the SUNDI heater chiller system ranges from 0.5 to 1200KW. It uses plate heat exchangers and pipe heaters to improve heating and cooling efficiency and meet your requirements for rapid heating and cooling.
2.Fully enclosed design
The SUNDI industrial chiller system adopts a fully enclosed pipe design, which does not absorb moisture at low temperatures and does not volatilize the medium at high temperatures, effectively extending the service life of the heat transfer liquid and reducing operating costs.
3.Magnetic drive pump
The SUNDI dynamic temperature control system chiller is equipped with a magnetic drive pump, which does not use mechanical seals, so there is no shaft seal leakage problem, and you don’t have to worry about the safety hazards caused by leakage. At the same time, we can also use variable frequency control according to your needs.
Why Choose LNEYA ?
As a chiller manufacturer, we provide comprehensive OEM services. Customizable items include but are not limited to:
- Cooling and heating capacity
- Explosion-proof type
- Casing material
- Accessory brand
- Screen size
- 통신 프로토콜
- Power supply voltage
- If you have any customization requirements, please contact us.
You can choose Ethernet interface, RS232 interface, Profibus-DP interface, external touch screen, etc.
We generally use cold-rolled plate sprayed RAL7035 housing. If you like other materials, we can also customize it.
We provide a variety of standard inlet and outlet interface sizes.
Support customization of isolation explosion-proof or positive pressure explosion-proof according to application scenarios
