AES Series Thermal Stream Temperature Forcing System

애플리케이션

AES series for Automatic test equipment in semiconductor, aerospace, military and other industries.

Such as ATE is used to measure the output signal of semiconductor devices，Used to evaluate the properties and performance of DUT, UUT, EUT to ensure use.

지원 받기

문의 @ 이메일

제품 특징

먼저Temperature control range: -120℃～225℃

둘째Temperature control accuracy: ±0.1℃

셋째High temperature 225℃ direct cooling

넷째Cooling test using special gas

제품 매개변수

The output airflow cover of the testing machine will be covered bythe test product to form a test chamber with a relatively closedspace. The high or low temp airflow output by the testing machinewill cause the surface temp of the test product to change drastically,thus completing the corresponding high and low temp impact test.

It can isolate one lC or original component among many componentsand separately perform high and low tempimpact withoutaffecting other surrounding devices. Compared with the traditionalthermal shock test box, the temp impact rate is faster.

Compared to the traditional thermostat, there are several features:
Temperature range: -120 °C ~ +300 °C;
The temperature rise and fall is very fast, -55 °C ~ 150 °C < 10 seconds;
Temperature control accuracy: ±1 °C;
Temperature setting capability: ±0.1 °C;
Temperature display capability: ±0.1 °C;
Maximum air flow: 25m3/h;
Real-time monitoring of the real temperature of the IC under test to achieve closed-loop feedback and adjust the gas temperature in real time;
The temperature rise and fall time is controllable, programmable operation, manual operation and remote control.

온도 범위	-40℃～225℃	-60℃～225℃	-80℃～225℃	-100℃～225℃	-120℃～225℃
온도 정확도	±0.1℃（Steady state outlet temperature）
Air requirements	Air filter < 5um air oil content < 0.1um air temp and humidity：5℃-32℃ 0-50%RH
Air treatment capacity	10m³/h-m³/h pressure 5bar-7.6bar
스로틀링 방법	전자식 팽창 밸브
컨트롤러	PLC Controller
표시 및 기록	The pressure of the refrigeration system is realized by a pointer pressure gauge, and the pressure of the circulation system is detected by a pressure sensor and displayed on the touch screen.
주요 구성 요소	Danfoss drying filter, Casto solenoid valve, Danfoss pressure controller, EBM fan ( air-cooled ), Danfoss / Emerson oil separator, SMC filter, Emerson electronic expansion valve, Johnson pressure sensor
압축기	Tecumseh,Dorin
High temp cooling	Possess high-temperature 225℃ direct cooling technology to meet the target and quickly cool down during high-temperature operation.
Process control	원격 목표 온도는 자체 생성 된 모델 무료 자체 구축 트리를 결합하여 제어 할 수 있습니다. tree algorithm and cascade algorithm
크기	5406901320	5406901320	5406901320	80012001750	100015001850
