heat transfer equipments

ETCU +5℃~90℃

반도체 생산 및 테스트 공정의 온도 제어

ETCU 시리즈

5°C

최저

90°C

최고

±0.05°C

온도 제어 정확도


Contact LNEYA sales engineer for catalog or price.

모델 ETCU-005W ETCU-015W ETCU-030W ETCU-050W ETCU-100W ETCU-200W ETCU-300W
온도 범위 Cooling water temperature +5℃~90℃
온도 제어 정확도 ±0.05℃(Steady state outlet temperature)
냉각수 온도 7℃~30℃ Cooling water flow is controlled by Siemens/Honeywell regulating valves
냉각 용량 5kW 15kW 30kW 50kW 100kW 200kW 300kW
  Test conditions: When the maximum circulation amount, the temperature difference between
the temperature control temperature and the cooling water temperature is 15℃
순환 펌프 7~20L/min 5bar 15~40L/min 5bar 20~60L/min 5bar 40~110L/min 5bar 150~250L/min 5bar 250~500L/min 5bar 400~650L/min 5bar
탱크 용량 5L 10L 20L 30L 60L 120L 240L
치수 cm 480*750*390 480*750*390 480*750*500 Customization Customization Customization Customization

높은 정밀도와 높은 효율성을 보장하는 열쇠

LNEYA heat transfer equipments applications:

40 ℃ 이내의 가열 방식은 압축기 고온 가스 가열 완전 밀폐형 설계를 채택하고 기계는 24 시간 동안 연속적으로 작동합니다.

프론트엔드에서 백엔드까지 전체 반도체 공정 흐름을 안정적이고 신뢰성 있게 보장합니다.

Other models for semiconductor industry

FLTZ 5~90

Process chillers

Temp range -25~90℃

Temp accuracy ±0.05℃

Send Inquiry Now

FLTZ -25~90

Thermal chillers

Temp range 5~90℃

Temp accuracy ±0.05℃

Send Inquiry Now

FLTZ -80~90

Recirculating water chillers

Temp range -80~90℃

Temp accuracy ±0.05℃

Send Inquiry Now

FLTZ -45~90

Low temperature chillers

Temp range -40~90℃

Temp accuracy ±0.05℃

Send Inquiry Now

Whether you need a Heat Exchange Chiller for temperature control through heat transfer, require customized heat transfer devices for different heat exchange scenarios, or need other types of chillers, LNEYA can provide the support you need. Our R&D team, engineers, designers, and product experts will deliver solutions through reliable products, professional technology, and responsible service.

Send Your Inquiry Now →

글로벌 서비스

30,000명 이상의 고객에게 서비스를 제공했습니다.
20개국 이상에 수출되었습니다.

인증 특허

CE 인증, SGS 인증, ISO 인증을 획득했습니다.

판매 후 서비스

포괄적인 기술 교육을 제공합니다.
연중무휴 솔루션으로.

전문 팀

2010년에 설립되어 15년의 업계 경력을 보유하고 있습니다.
20%의 직원이 기술자입니다.

품질 관리

육안 검사.
성능 테스트.
전기 안전 테스트.

적합한 냉각기를 찾을 수 없나요? 또는 냉각기를 선택하는 방법을 모르시나요? 지금 바로 문의하여 냉각기 세부 정보 및 가격을 알아보세요.

Heat transfer equipment refers to devices used to transfer heat between two or more fluids. This process typically requires a large amount of working or utility media, such as water or air, which absorb or release heat from more valuable fluids (e.g., crude oil, petrochemical raw materials, and fluidized bed products). Heat transfer equipment plays a vital role in various industries by regulating temperatures and enabling efficient heat exchange in processes like heating, cooling, and energy recovery.

Yes, our recirculation chillers are exported to more than 20 countries, and we have agents in the United States, Canada, Australia, Russia, South Korea and other countries. You can contact the local agent or contact us directly to purchase equipment.

*
*
