Water chiller & Air chiller
LENYA High–Precision 냉각기 ensure the controllable accuracy of ± 0.05℃
higher temperature control accuracy, wider temperature control range, and faster cooling speed.
FLTZ 5℃~90℃
— Single Channel Chiller
“W”represents optional water cooling, default air cooling.
| FLTZ SERIES | 002 002W |
003 003W |
004 004W |
006 006W |
008 008W |
010 010W |
015 015W |
| 온도 범위 | 5℃～90℃ | ||||||
| 온도 제어 정확도 | ±0.05℃（Steady state outlet temperature） | ||||||
| Cooling capacity @10℃ | 6kW | 8kW | 10kW | 15kW | 20kW | 25kW | 40kW |
| 냉매 | R410A | ||||||
| Cooling water flow @20℃ | 1.5m³/h | 2m³/h | 2.5m³/h | 4m³/h | 4.5m³/h | 5.6m³/h | 9m³/h |
| Internal circulating fluid volume | 4L | 5L | 6L | 8L | 10L | 12L | 20L |
| 확장 탱크 용량 | 10L | 10L | 15L | 15L | 20L | 25L | 35L |
| 냉매 | R410A | ||||||
| 연결 크기 | ZG1/2 | ZG1/2 | ZG3/4 | ZG3/4 | ZG3/4 | ZG1 | ZG1 |
| Cooling water connection size | ZG1/2 | ZG1/2 | ZG3/4 | ZG1 | ZG1 | ZG1 | ZG1 1/8 |
| Refrigerating medium | Silicone oil, fluorinated liquid, polyol aqueous solution, DI, etc. (DI temp needs to be controlled above 10 ℃) | ||||||
| 공정 온도 제어 | The remote target temperature can be controlled by combining the self created model free self built tree algorithm and cascade algorithm |
||||||
Avantages of Process Chillers
Other process chillers in the same series
Temp range -25~90℃
온도 정확도 ±0.05℃
Temp range -45~90℃
온도 정확도 ±0.05℃
Temp range -80~90℃
온도 정확도 ±0.05℃
Temp range -100~90℃
온도 정확도 ±0.05℃
Tailor-made suitable solutions
30,000명 이상의 고객에게 서비스를 제공했습니다.
20개국 이상에 수출되었습니다.
CE 인증, SGS 인증, ISO 인증을 획득했습니다.
포괄적인 기술 교육을 제공합니다.
연중무휴 솔루션으로.
2010년에 설립되어 15년의 업계 경력을 보유하고 있습니다.
20%의 직원이 기술자입니다.
육안 검사.
성능 테스트.
전기 안전 테스트.
LNEYA have received many honors.
LNEYA won the “2021 Excellent Reactor Technology Supplier” from Corning Incorporated
2024 China Energy Storage Industry Best Temperature Control Technology Solution Award,and E certification.In addition, you can enjoy 24-hour after-sales service.We will always respond to your needs
Of course! Our 수냉식 칠러 can be customized according to specific temperature ranges and specific cooling medium, etc. Additionally, if you need positive pressure explosion-proof or isolation explosion-proof, we also support non-standard customization.
You can rest assured about this. We offer comprehensive after-sales service, including installation and commissioning, technical training, one-year free warranty and other services. We hold the value that customer and quality is the first. We ensure you can operate the process chillers proficiently and use it for a long time.
